24T3 PRO 11 : TCL DC INVERTER SPLIT

General & Capacity Specifications

• Brand / Series: TCL / BreezeIN Pro (T-PRO Series)
• Model: TAC-24T3-PRO-11 (24T3-PRO-11)
• Capacity / Size: 2.0 Ton
• Type: Wall-Mounted Split Inverter (Heat & Cool)
• Compressor: T3 Tropical Twin Rotary Inverter Compressor
• Refrigerant: Eco-Friendly R32 (Charge: 1.060 kg)

Performance & Electrical Data

• Cooling Capacity: 24,000 – 25,000 BTU/h
• Heating Capacity: 25,000 – 26,000 BTU/h
• Cooling Power Input: 200W – 2,600W (up to 3,100W depending on load)
• Heating Power Input: 230W – 2,600W
• Running Current: 1.5A – 13.0A (Cooling)
• Rated Voltage & Frequency: 220–240V, 50Hz (Wide-voltage operation range: ~145V to 265V)
• Extreme Climate Operation: Designed for ambient cooling performance up to 60°C

Airflow & Comfort Features

• Air Volume: 1,400 m³/h (Indoor Air Volume)
• Airflow Technology: 4D Airflow / 4-Way Swing (Up/Down & Left/Right)
• Gentle Breeze Mode: Utilizes micro-holes on S-shaped vanes for draft-free, soft cooling
• Smart Air Flow & I Feel Function: Precision temperature sensing via the remote control
• Noise Levels: Indoor ~51 dB(A) | Outdoor ~57 dB(A)

Smart & Control Features

• Wi-Fi / IoT Control: Built-in Wi-Fi via the TCL Home App
• Voice Assistant Support: Compatible with Google Assistant
• Generator Mode / Ampere Lock: Multi-step power restriction (e.g., 50%, 75%, 100% or variable ampere control)
• Display Technology: Hidden LED Display
• OTA Updates & Smart Memory: Supported

Hygiene, Cleaning & Build

• Self-Cleaning / Deep Clean: 56°C High-Temperature Self-Sterilization & 4-level deep clean technology
• Maintenance Reminders: Auto filter-cleaning reminder and leak detection
• Coating: Gold Fin protection on both evaporator and condenser coils

Dimensions & Weight

• Indoor Unit Dimensions (W × D × H): 1097 × 332 × 222 mm
• Outdoor Unit Dimensions (W × D × H): 920 × 380 × 699 mm
• Indoor Unit Weight: 15 kg
• Outdoor Unit Weight: 32 kg – 37 kg
• Outdoor Protection Rating: IPX4

Official Warranty (Pakistan)

• Compressor: 10 Years
• PCB Kit: 4 Years
• General / Parts: 1 Year
