12SVN AI : TCL DC INVERTER SPLIT

General & Technical Specifications

• Brand / Series: TCL / SaveIN AI Series
• Model Variants: TAC-12SVN-AI-11, 12SVN-AI-21, TAC-12SVN-AI-41 (Heat & Cool / Cool-Only variants exist)
• Product Type: Wall-Mounted Split Inverter AC
• Capacity: 1.0 Ton (12,000 BTU/h)
• Compressor Type: T3 Rotary DC Inverter Compressor (designed for high ambient temperatures)
• Refrigerant: Eco-friendly R32 (0.530 kg charge)

Performance & Operational Limits

• Cooling Capacity: 12,000 BTU/h (Cooling power input: 160W–1,600W)
• Heating Capacity: 12,000 BTU/h (Heating power input: 150W–1,350W, on Heat & Cool models)
• Cooling / Heating Current: 1.3–8.5A (Cooling) | 1.3–9.0A (Heating)
• Voltage & Frequency: 220–240V, 50Hz (Low-voltage startup capability starting around 155V–160V)
• Ambient Temperature Range: Cooling capability up to 62°C | Heating capability down to -20°C

Smart & AI Features

• T-AI Energy Saving Chipset: Dynamic AI algorithm for optimized power consumption and extra energy savings
• Gen Mode: 3-to-6 level Gen Mode for generator compatibility and current limitation during power fluctuations
• Connectivity: Built-in Wi-Fi control via the TCL Home App (compatible with smart ecosystems)
• Smart Functions: Smart Memory, Smart Learning, and Easy OTA (Over-The-Air) firmware updates

Airflow & Comfort

• Airflow Technology: Coanda Airflow effect for uniform, draft-free room distribution
• Indoor Air Volume: 570 m³/h
• Noise Levels: Indoor ~45 dB(A) | Outdoor ~54 dB(A)

Maintenance & Build

• Self-Cleaning: Indoor self-cleaning / high-temperature sterilization (56°C cycle)
• Additional Utilities: Filter cleaning reminder, refrigerant leakage detection, Graphene coating, and pure copper condenser
• Unit Dimensions & Weight: Indoor unit weighs 7.3 kg; Outdoor unit weighs 22 kg (Outdoor protection rating: IPX4)

Warranty

• 10 Years on Compressor
• 4 Years on PCB Kit
• 1 Year on Parts & Service
